LED Video Wall Outdoor 9.5′ X 6.3′ P5mm Iron Fixed

$8,699.00

SKU: P5FOUT9X6 Category:
3 years
warranty
In stock
ready to ship
Technical
support
Financing
Available
US-Based
Company
3 years
warranty
In stock
ready to ship
Technical
support
Financing
Available
US-Based
Company
GET A FREE QUOTE NOW!
Contact Us Now!

The new 9.5 ′ x 6.3 ′ P5mm outdoor LED video wall is the perfect option for the ideal transmission of large advertising campaigns in outdoor areas. Thanks to its sophisticated style, it is one of the most visibly attractive elements for your audience.

The new 9.5 ′ x 6.3 ′ P5mm outdoor LED video wall is the perfect option for the ideal transmission of large advertising campaigns in outdoor areas. Thanks to its sophisticated style, it is one of the most visibly attractive elements for your audience.

The P5 is specifically designed for large outdoor congregations or events, and provides an excellent image quality with intense brightness over a considerable distance. Its price point is extremely competitive, when compared to prior models. Such a package is the right fit, when frugality and practicality are the priority.

The P5 is specifically designed for large outdoor congregations or events, and provides an excellent image quality with intense brightness over a considerable distance. Its price point is extremely competitive, when compared to prior models. Such a package is the right fit, when frugality and practicality are the priority.

VIEW DISTANCE

RECEIVING CARD

MRV NovaStar 3840 Hz

By NovaStar, single MRV208-1
supports resolutions up to
256×256@60Hz. Supporting
various functions, can significantly
improve the display effect and user
user experience.

Full front serviceable

Magnetic Modules

Easily removable

magnetic module system

To simplify assembly, repair or
replacement of components.
They can be removed with a special
tool or manually of components.

Easily removable

magnetic module system

To simplify assembly, repair or replacement of.
They can be removed with a special tool or manually of components.

Distance is important

This LED wall is made up of 6 P5mm panels, following a 3×2 dimension. Each panel has a pixel density of 192 x 192. These panels are designed to project the highest quality image, with an optimal viewing distance of at least 25 feet per its 5mm pixel pitch. Thus, the viewer does not have to be that close to the product. Additionally, it comes with IP65 rain resistance – providing additional protection and durability, even in the toughest weather conditions.

Assemblies available

Easy installation

Ground support

Bar and ladder truss that creates a stable
system to support your screen in various
configurations and offers flexibility in
height as well as width.

Ground support

Bar and ladder truss that creates a stable system to support your screen in various configurations and
offers flexibility in height as well as

Wall Mountable

It is the most common support and above
all the most stable considering the type of
construction where it is mounted, since it is
screwed through

Wall Mountable

It is the most common support and above all the most stable considering the type of construction where it is mounted, since it is screwed through

TRUSS SYSTEMS

Manufactured with heavy-dutyaluminum material, ideal for overhead truss system, a ceiling grid, a crane, or other support structure from above.

TRUSS SYSTEMS

Manufactured with heavy-duty aluminum
material, ideal for overhead truss system, a
ceiling grid, a crane, or other support
structure from above.

Corner protection

It’s all controlled

This LED screen is perhaps one of the most profitable on the market, due to its affordability and its small size – providing an aspect ratio 3: 2. Furthermore the card that controls these panels are from the M3 series, one of the most recommended control cards on the market – with its seamless integration with audio systems.

Corner protection

It’s all controlled

This LED screen is perhaps one of the most profitable on the market, due to its affordability and its small size – providing an aspect ratio 3: 2. Furthermore the card that controls these panels are from the M3 series, one of the most recommended control cards on the market – with its seamless integration with audio systems.

PACKAGE INCLUDES

(1) VIDEO PROCESSOR NovaStar Mi 1000 WITH HDMI, DVI AND VGA INPUTS
(6) NovaStar P5mm Iron Fixed Outdoor LED video tiles
(6) LOCKING POWER LINK CABLES
(3) HANGING BARS FOR RIGGING
(1) Cat6 25ft cable
(3) LOCKING POWER TO EDISON LINK CABLES
(6) Data Cat6 link cables
SPARE PARTS INCLUDED
novastar-p5-outdoor-led-video-wall-panel-church-house-of-worship-flight-case

PACKAGE INCLUDES

(1) VIDEO PROCESSOR NovaStar Mi 1000 WITH HDMI, DVI AND VGA INPUTS
(6) NovaStar P5mm Iron Fixed Outdoor LED video tiles
(6) LOCKING POWER LINK CABLES
(3) HANGING BARS FOR RIGGING
(1) Cat6 25ft cable
(3) LOCKING POWER TO EDISON LINK CABLES
SPARE PARTS INCLUDED
novastar-p5-outdoor-led-video-wall-panel-church-house-of-worship-flight-case
(6) Data Cat6 link cables

At the customer’s service

To provide the best service to our users we offer: free shipping, a 3-year warranty for the LED video wall and all its parts & 24/7 tech support service at your disposal. Make sure to ask about our installation services!

TECHNICAL SPECIFICATIONS

KEY FEATURES:

Full Front Service / Magnetic Modules
Turn-key solution
Easy installation
Ground support compatible (sold separately here)
Download full specifications here
Technical support available
3-year warranty included for all parts
USA based
In stock

PACKAGE INCLUDES:

(6) NovaStar P5mm Outdoor LED video tiles
(1) Video Processor with HDMI, DVI and VGA Inputs
(3) Hanging bars for rigging
(1) Cat6 25ft cable
(6) Data Cat6 link cables
(6) Locking Power Link Cables
(3) Locking Power to Edison Cables
Spare parts included

CONTROL SYSTEM:

Control Mode: NovaStar Synchronous System with Control via DVI
Frame Update Frequency: 50-60Hz
Scan Mode: 1/8
Refresh Rate: 3840Hz
Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Brightness Correction: Pixel, Module, Cabinet

SPECS:

Pixel Pitch: 5mm
LED Configuration: 3-in-1 SMD1820/1921 LED
Pixel Density: 192 x 192 per panel
Size: 37.8” x 37.8” x 3.5” / 960 x 960 x 88mm
Module Quantity: 18 per panel 320 x 160mm
Weight: 62lbs. / 30.9Kg

OPTICAL RATINGS:

Brightness: 5200 NITS
View Angle: Horizontal 140°/Vertical 140°
Distance: 25ft (7.6m)
Brightness Adjustment: 0~100% 100 Levels

ENVIRONMENTAL:

Operating Life: 100,000 Hours
Protection Level: IP65 (Front and Back)

POWER SUPPLY:

Operation Power: 100~240V 50-60Hz
Max. Power Consumption: 425W/per panel
Ave. Power Consumption: 240W/per panel
Connections Power/Data: Locking power In/Out; Data EtherCon In/Out

Large LED Screen Display 25.2’ x 11’ P1.53mm

With the pixel pitch of 1.53mm being the smallest of our indoor line – all images transmitted on the 25.2’ x 11’ LED video wall screen will have the highest and sharpest image quality – for maximum impact on your audience. When reproducing hyper-realistic virtual environments in front of a group of impatient spectators – this package is the right choice. With the P1.53mm package, you’ll have the absolute best, premium experience with ultra high resolution, vibrant colors, and smooth motion.


Key Features:

  • Full Front Service / Magnetic Modules
  • Turn-key solution
  • Easy installation
  • Ground support compatible (sold separately here)
  • Technical support available
  • 3-year warranty included for all parts
  • USA based
  • In stock

Package Includes:

  • (84) NovaStar P1.53mm Indoor LED video tiles
  • (2) NovaStar VX6S
  • (12) Hanging bars for rigging
  • (10) Cat6 25ft cable
  • (84) Data Cat6 link cables
  • (84) Locking Power Link Cables
  • (5) Locking Power to Edison Cables
  • Spare parts included

Specs:

  • Pixel Pitch: 1.53mm
  • High Refresh Rate: 3840hz
  • Full Front Service / Magnetic Modules
  • LED Configuration: 3-in-1 SMD1515 LED
  • Pixel Density: 416 x 312 per panel
  • Size: 25.2” x 18.9” x 2.9” / 640 x 480 x 75mm
  • Module Quantity: 6 per panel 320 x 160mm
  • Weight: 21.6lbs / 9.8Kg

Optical Ratings:

  • Brightness: 800 NITS
  • View Angle: Horizontal 140°/Vertical 140°
  • Distance: 5ft (1.5m)
  • Brightness Adjustment: 0~100% 100 Levels

Power Supply:

  • Operation Power: 100~240V 50-60Hz
  • Max. Power Consumption: 140W/per panel
  • Ave. Power Consumption: 70W/per panel
  • Connections Power/Data: Locking power In/Out; Data EtherCon In/Out

Control System:

  • Control Mode: NovaStar Synchronous System with Control via DVI
  • Frame Update Frequency: 50-60Hz
  • Scan Mode: 1/28
  • Refresh Rate: 3840Hz
  • Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
  • Brightness Correction: Pixel, Module, Cabinet

Environmental:

  • Operating Life: 100,000 Hours
  • Protection Level: IP45 (Front and Back)

The Mirackle® P1.53 is a high resolution video panel from Mirackle®. Each panel has a pixel pitch of 1.53mm with a configuration of a 3-in-1 RGB SMD2020 LED. These panels are specifically designed to be viewed at a close distance. Ideal for tv studios, virtual productions and even domestic use. This line of panels will definitely upgrade any presentation, event or video production.

Mirackle® offers full packages and turn-key solutions by giving you everything you need to get up and running. This package comes with video processors, software, cabling, rigging bars and flight cases.

Download full specifications here Key Features:
  • IP65 Rated
  • Turn-key solution
  • Easy installation
  • Ground support compatible (sold separately here)
  • Technical support available
  • 3-year warranty included for all parts
  • USA based
  • In stock

Specs:

  • Pixel Pitch: 5mm
  • LED Configuration: SMD1921
  • Pixel Density: 192 x 192 per panel
  • Size: 37.9” x 37.9” x 3.5” / 960 x 960 x 90mm
  • Module Quantity: 18 per panel 320 x 160mm
  • Weight: 70lbs. / 32Kg
Optical Ratings:
  • Brightness: 5500 NITS
  • View Angle: Horizontal 170°/Vertical 120°
  • Distance: 16ft.
  • Brightness Adjustment: 0~100% 100 Levels
Power Supply:
  • Operation Power: 110~240V 5V-60A
  • Max. Power Consumption: 900W/per panel
  • Ave. Power Consumption: 360W/per panel
  • Connections Power/Data: Locking power In/Out; Data EtherCon In/Out
Control System:
  • Control Mode: NovaStar Synchronous System with Control via DVI
  • Frame Update Frequency: 50-60Hz
  • Scan Mode: 1/8
  • Refresh Rate: 3840Hz
  • Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
  • Brightness Correction: Pixel, Module, Cabinet
Environmental:
  • Operating Life: 100,000 Hours
  • Protection Level: IP65 (Front and Back)
Download full specifications here Key Features:
  • Full Front Service / Magnetic Modules
  • IP65 Rated
  • Turn-key solution
  • Easy installation
  • Ground support compatible (sold separately here)
  • Technical support available
  • 3-year warranty included for all parts
  • USA based
  • In stock

Specs:

  • Pixel Pitch: 5mm
  • LED Configuration: SMD1921
  • Pixel Density: 192 x 192 per panel
  • Size: 37.9” x 37.9” x 3.5” / 960 x 960 x 90mm
  • Module Quantity: 18 per panel 320 x 160mm
  • Weight: 70lbs. / 32Kg
Optical Ratings:
  • Brightness: 5500 NITS
  • View Angle: Horizontal 170°/Vertical 120°
  • Distance: 16ft.
  • Brightness Adjustment: 0~100% 100 Levels
Power Supply:
  • Operation Power: 110~240V 5V-60A
  • Max. Power Consumption: 900W/per panel
  • Ave. Power Consumption: 360W/per panel
  • Connections Power/Data: Locking power In/Out; Data EtherCon In/Out
Control System:
  • Control Mode: NovaStar Synchronous System with Control via DVI
  • Frame Update Frequency: 50-60Hz
  • Scan Mode: 1/8
  • Refresh Rate: 3840Hz
  • Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
  • Brightness Correction: Pixel, Module, Cabinet
Environmental:
  • Operating Life: 100,000 Hours
  • Protection Level: IP65 (Front and Back)
Dimensions 9.5 in
