The Indoor line brings a new version of video panels: the 21 ′ x 11 ′ P1.86mm LED wall screen, which allows a very close viewing distance between the screen and the observer, at only 4 feet of separation. This allows transmitting information and visuals in the highest quality.
The Indoor line brings a new version of video panels: the 21 ′ x 11 ′ P1.86mm LED wall screen,
which allows a very close viewing distance between the screen and the observer, at only 4 feet of separation.
This allows transmitting information and visuals in the highest quality.
This P1.86mm package is our most superior LED turn-key package. If you want to get the most out of LED technology for digital signage and audiovisual projects – this package is the right choice.
This P1.86mm package is our most superior LED turn-key package. If you want to get the most out of LED technology
for digital signage and audiovisual projects – this package is the right choice.
VIEW DISTANCE
RECEIVING CARD
A8 NovaStar 7680 Hz
By NovaStar, A8s-N supports
various functions with the highest
resolution, enhances the display
efect and user experience.
Full front serviceable
Easily removable
magnetic module system
To simplify assembly, repair or
replacement of components.
They can be removed with a special
tool or manually of components.
Easily removable
magnetic module system
To simplify assembly, repair or replacement of.
They can be removed with a special tool or manually of components.
Versatile high tech
This screen has a ultra-fine pixel pitch which allows a minimum view distance from 4 feet away, or approximately 1.2 meters. They are specifically designed to be viewed at a close distance. Ideal for tv studios, virtual productions and even domestic use. 160 degrees of viewing angle make this product incredibly versatile covering a wide range of possibilities. This line of panels will definitely upgrade any presentation, event or video production.
Assemblies available
Ground support
Bar and ladder truss that creates a stable
system to support your screen in various
configurations and offers flexibility in
height as well as width.
Ground support
Bar and ladder truss that creates a stable system to support your screen in various configurations and
offers flexibility in height as well as
Wall Mountable
It is the most common support and above
all the most stable considering the type of
construction where it is mounted, since it is
screwed through
Wall Mountable
It is the most common support and above all the most stable considering the type of construction where it is mounted, since it is screwed through
TRUSS SYSTEMS
Manufactured with heavy-dutyaluminum material, ideal for overhead truss system, a ceiling grid, a crane, or other support structure from above.
TRUSS SYSTEMS
Manufactured with heavy-duty aluminum
material, ideal for overhead truss system, a
ceiling grid, a crane, or other support
structure from above.
Corner protection
MAXIMUM SAVINGS AND PRACTICALITY
Its long service life, with more than 100,000 hours of operation, make this screen extremely economical and very proftable. The weight per panel is 21 pounds, just over 9.6 Kg, which makes it light and easy to transport. Also, in addition to being compatible with ground support, it can be easily manipulated & handled. These LED video panels have an anti-reflective GOB mask that nullifies moiré effect. It is used in applications requiring LED front module protection, such as broadcasting and virtual studios.
Corner protection
MAXIMUM SAVINGS
AND PRACTICALITY
Its long service life, with more than 100,000 hours of operation, make this screen extremely economical and very proftable. The weight per panel is 21 pounds, just over 9.6 Kg, which makes it light and easy to transport. Also, in addition to being compatible with ground support, it can be easily manipulated & handled. These LED video panels have an anti-reflective GOB mask that nullifies moiré effect. It is used in applications requiring LED front module protection, such as broadcasting and virtual studios.
PACKAGE INCLUDES
PACKAGE INCLUDES
THE BEST SALES AND
AFTER-SALES SERVICE
With free shipping to all states in the country, this package is turn-key, so the product and processing system is delivered ready to be used. Our sales and post-sales service has received a 5-star rating on all our platforms. Our website offers technical phone support, installation and maintenance services, as well as helpful videos. Make sure to ask about our installation services!
TECHNICAL SPECIFICATIONS
(70) Mirackle® NovaStar P1.86mm Indoor LED video tiles
(21) VX1000 NovaStar Video Processor with HDMI, DVI and VGA inputs
(10) Hanging bars for rigging
(10) Cat6 25ft cable
(70) Data Cat6 link cables
(70) Locking Power Link Cables
(9) Locking Power to Edison Cables
Spare parts included
Control Mode: NovaStar Synchronous System with Control via DVI
Frame Update Frequency: 50-60Hz
Scan Mode: 1/40
Refresh Rate: 3840Hz
Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Brightness Correction: Pixel, Module, Cabinet
Pixel Pitch: 1.86mm
High Refresh Rate: 3840hz
Full Front Service / Magnetic Modules
LED Configuration:
3-in-1 SMD1515 LED
Pixel Density: 342 x 256 per panel
Size: 25.2” x 18.9” x 3” / 640 x 480 x 75mm
Module Quantity:
6 per panel 320 x 160mm
Weight: 21.6lbs / 9.8Kg
Brightness: 700 NITS
View Angle: Horizontal 160°/Vertical 160°
Distance: 4ft. / 1.2m
Brightness Adjustment: 0~100% 100 Levels
Operating Life: 100,000 Hours
Protection Level: IP45 (Front and Back)
Operation Power: 100~240V 50-60Hz
Max. Power Consumption: 200W/per panel
Ave. Power Consumption: 120W/per panel
Connections Power/Data: Locking power In/Out; Data EtherCon In/Out
LED Video Wall Screen 25.2′ x 11′ P1.86mm Indoor
With the pixel pitch of 1.86mm being the smallest of our indoor line – all images transmitted on the 21’ x 11’ LED video wall screen will have the highest and sharpest image quality – for maximum impact on your audience. When reproducing hyper-realistic virtual environments in front of a group of impatient spectators – this package is the right choice. With the P1.86mm package, you’ll have the absolute best, premium experience with ultra high resolution, vibrant colors, and smooth motion. Download full specifications here Key Features:- Full Front Service / Magnetic Modules
- Turn-key solution
- Easy installation
- Ground support compatible (sold separately)
- Technical support available
- 3-year warranty included for all parts
- USA based
- In stock
- (84) Mirackle® NovaStar P1.86mm Indoor LED video tiles
- (2) VX1000 NovaStar Video Processor with HDMI, DVI and VGA inputs
- (12) Hanging bars for rigging
- (10) Cat6 25ft cable
- (84) Data Cat6 link cables
- (84) Locking Power Link Cables
- (5) Locking Power to Edison Cables
- Spare parts included
Specs:
- Pixel Pitch: 1.86mm
- High Refresh Rate: 3840hz
- Full Front Service / Magnetic Modules
- LED Configuration: 3-in-1 SMD1515 LED
- Pixel Density: 342 x 256 per panel
- Size: 25.2” x 18.9” x 3” / 640 x 480 x 75mm
- Module Quantity: 6 per panel 320 x 160mm
- Weight: 21.6lbs / 9.8Kg
- Brightness: 800 NITS
- View Angle: Horizontal 160°/Vertical 160°
- Distance: 5ft. / 1.5m
- Brightness Adjustment: 0~100% 100 Levels
- Operation Power: 100~240V 50-60Hz
- Max. Power Consumption: 200W/per panel
- Ave. Power Consumption: 120W/per panel
- Connections Power/Data: Locking power In/Out; Data EtherCon In/Out
- Control Mode: NovaStar Synchronous System with Control via DVI
- Frame Update Frequency: 50-60Hz
- Scan Mode: 1/40
- Refresh Rate: 3840Hz
- Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
- Brightness Correction: Pixel, Module, Cabinet
- Operating Life: 100,000 Hours
- Protection Level: IP45 (Front and Back)
Related products
-
Indoor
LED Video Wall Screen 19.7′ x 9.8′ P3.91mm Indoor Turn-key
Rated 0 out of 5$33,599.00$30,799.00 ADD TO CART -
Indoor
LED Video Wall Screen 16.4′ x 9.8′ P2.97mm Indoor Turn-key
Rated 0 out of 5$31,199.00$28,199.00 ADD TO CART -
Indoor
LED Video Wall Screen 9.8′ x 6.6′ P2.97mm Indoor Turn-key
Rated 0 out of 5$13,999.00$13,199.00 ADD TO CART
LED Video Wall Screen 21′ x 11′ P1.86mm Indoor
The Indoor line brings a new version of video panels: the 21 ′ x 11 ′ P1.86mm LED wall screen, which allows a very close viewing distance between the screen and the observer, at only 5 feet of separation. This allows transmitting information and visuals in the highest quality. This P1.86mm package is our most superior LED turn-key package. If you want to get the most out of LED technology for digital signage and audiovisual projects – this package is the right choice. Download full specifications here Key Features:- Full Front Service / Magnetic Modules
- Turn-key solution
- Easy installation
- Ground support compatible (sold separately)
- Technical support available
- 3-year warranty included for all parts
- USA based
- In stock
- (70) Mirackle® NovaStar P1.86mm Indoor LED video tiles
- (2) VX1000 NovaStar Video Processor with HDMI, DVI and VGA inputs
- (10) Hanging bars for rigging
- (9) Cat6 25ft cable
- (70) Data Cat6 link cables
- (70) Locking Power Link Cables
- (4) Locking Power to Edison Cables
- Spare parts included
Specs:
- Pixel Pitch: 1.86mm
- High Refresh Rate: 3840hz
- Full Front Service / Magnetic Modules
- LED Configuration: 3-in-1 SMD1515 LED
- Pixel Density: 342 x 256 per panel
- Size: 25.2” x 18.9” x 3” / 640 x 480 x 75mm
- Module Quantity: 6 per panel 320 x 160mm
- Weight: 21.6lbs / 9.8Kg
- Brightness: 800 NITS
- View Angle: Horizontal 160°/Vertical 160°
- Distance: 5ft. / 1.5m
- Brightness Adjustment: 0~100% 100 Levels
- Operation Power: 100~240V 50-60Hz
- Max. Power Consumption: 200W/per panel
- Ave. Power Consumption: 120W/per panel
- Connections Power/Data: Locking power In/Out; Data EtherCon In/Out
- Control Mode: NovaStar Synchronous System with Control via DVI
- Frame Update Frequency: 50-60Hz
- Scan Mode: 1/40
- Refresh Rate: 3840Hz
- Support Input: Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
- Brightness Correction: Pixel, Module, Cabinet
- Operating Life: 100,000 Hours
- Protection Level: IP45 (Front and Back)
